Main Features

---

• Machine arrangement - single sided
• Max. Spindles - 48(in multiples of 3)
• Installed power per spindle - 0.150Kw
• Input power - 415/380/220 v ac three phase + n + e
• Individual ac inverter for every drum motor for soft start
• Pre feeder for reducing yarn tension variation while unwainding from hanks
• Separate common inverter for controlling speed of pre-feeding motors
• Stepless speed variation from 0 to 750 mpm by frequency inverter
• Yarn sensing by electronic non contact type yarn detector
• Traverse - 6" - 8" - 10"
• Electronic anti patterning
• Single sided pacakage holders suitable for 5 57 cones
• Maximum take-up package - 320mm
• Swift capable of holding hank upto 1000gms
• Swift circumference adjustable from 45" to 68"

---

Optional Extras

---

• Length Measuring system
• Splicer
• Waxing
